| TOUCH SPECIFICATIONS |
| Part number | 242100.510 |
| System Compability | 12Vdc to 380Vdc, Positive / Negative / Floating Distribution. Panel
Mount |
| Power consumption | Max 5.4W, Typical 2.4W |
| Display | Graphical 4,4 inches LCD display - Capacitive touch interface - 480
x RGB
x 272 resolution |
| Ethernet Ports | 2 x 10/100 BASE-T, Wi-Fi support w/ USB dogle |
| Serial Ports | RS-232 & RS-485 |
| USB | 2 x USB Type A Host |
| Removable media | uSD card, USB Flash Drive support |
| SNMP | v1, v2c, v3 w/ GET, SET & TRAPs – Eltek Enterprise MIB Branch 10 |
| Web Interface | Responsive HTML5, java script, encrypted w/TLS |
| Other network | SMTP Client, NTP Client, FTP/FTPS file transfer, MODBUS TCP |
| Buzzer | 75dB at 1m |
| IP Grade | 22 |
| Dimensions (WxHxD) | 174 x 78 x 41 mm (Cut-out: 153 x 68 mm) |
| BASIC |
| Part number | 242100.501 |
| Operating temperature | -20 to +70˚C (-4 to 158˚F) |
| Storage temperature | -40 to +85˚C (-40 to 185˚F) |
| Input voltage | 20-172 VDC (20 -75 VDC***) Shutdown: < 18 VDC |
| Power consumption | Max 1.5A Max 4.5A (3x LVD max loaded) |
| Contactor outputs | 3 x LVD control outputs |
| Configurable inputs | 3x NO/NC/Temperature: NTC probe |
System connections:
• Voltage sense
• Current sense
• Battery fuse*
• Load fuse* | 24V, 48V, 60V & 110V** systems
0-20mV and 0-60mV range shunts
Battery fuse sense, Open/Closed
Load fuse sense, Open/Closed, Pull- Up/Down, Diode Matrix |
| Ground fault | Simple bridge circuit detection |
| Max basic nodes | 8 units on a single CAN-bus |
| Dimensions (WxHxD) | 155 x 35 x 80 mm / 6.4 x 1.4 x 3.3” |
| BASIC INDUSTRIAL |
| Part number | 242100.601 |
| Operating temperature | -20 to +70˚C (-4 to 158˚F) |
| Storage temperature | -40 to +85˚C (-40 to 185˚F) |
| Power consumption | Max 1.6A |
| Electric isolation | 7 different isolated sections |
Customer connections:
• Configurable Inputs | 3x, “digital”, temperature / voltage /current measurements.
- NO/NC, Pull Up/Dn, Diode Matrix: -10V> +10V (2mV full range)
- Current measurements: 4-20mA (ext. sense resistor 100-500Ω)
- Temperature measurements: NTC probe |
| BASIC INDUSTRIAL - CONTINUED |
| • Relay outputs | 3x, NO-C-NO, 0-220V, 30W (max. 1A), configurable |
| • Serial communication | RS232C port and RS485 port |
| System connections: |
| • Voltage sense inputs | 3x, Max. 420VDC, Symmetry& battery monitoring |
| • Current sense inputs | 2x, for 20mV to 60mV current shunts |
| • Battery fuse sense inputs | 1x, NO/NC, Pull Up/Dn, Diode Matrix: -10V> +10V (2mV full range) |
| • Load fuse sense inputs | 1x, NO/NC, Pull Up/Dn, Diode Matrix: -10V> +10V (2mV full range) |
| • LVD contactor outputs | 3x, 10-420V, 1A, Configurable as latching or non-latching
LVD Supply input: 10-420V, 1A |
| • CAN interface | 2 x, CAN bus systems (separated and isolated) |
| • Earth fault detection | 1x, internal Isolation input |
| Power system compatibility | Industrial & Telecom, Positive, negative and floating DC
distributions |
| Max number of controller nodes | 10 on a single CAN-bus, in addition to Smartpack2 Master controller |
| Controller configuration | Front keys in the Smartpack2 Master controller, via CWUI in an
standard web browser (Controller’s Web-based User Interface)
and via PowerSuite application |
| Dimensions | (WxHxD) 146.0 x 146.0 x 45.6 mm / (5.7 x 5.7 x 1.8”) |
| I/O MONITOR (TYPE 2) |
| Configurable Inputs | 6x NO/NC/Analog Voltage [0-75V] |
| Alarm Outputs | 6x Relay–Dry/Form C
[Max 75V/2A/60W] |
| Max I/O Monitors | 14 units on a single CAN-bus |
| Power Consumption | Max 3.6W |
| Dimensions (WxHxD) | 135.1 x 23.5 x 59mm / 5.3 x 0.9 x 2.3” |
| CONTROL DEVICES/CAN NODES |
| 242100.300 | Battery Monitor |
| 242100.301 | Load Monitor |
| 242100.304 | I/O Monitor (Outdoor) |
| 242100.306 | I/O Monitor Type 3 |
| 242100.200 | Smartnode RS232/485 |
| 242100.510 | Smartpack2 Touch |
| 242100.501 | Smartpack2 Basic |
| 242100.601 | Smartpack2 Basic Industrial |
| 242100.603 | Fleximonitor |
| 242100.502 | I/O Monitor – Type 2 |
| | |
