| Rectiverter 48V 241123.100 2301500 481200 & 115750 48600 |
| Model | 230/1500
48/1200 | 230/1500
48/150 | 230/1500
48/0 | 115/750
48/600 | 115/750
48/75 | 115/750
48/0 |
| Part number | 241123.100 | 241123.101 | 241123.102 | 241123.100L | 241123.100L | 241123.102L |
| INPUT DATA |
| Voltage range (nominal) | 230 VAC / 200 - 240 VAC | 115 VAC / 100 - 127 VAC |
| Frequency (default inverter mode) | 50 Hz (adaptive) | 60 Hz (adaptive) |
| Frequency (set-able inverter mode) | 50Hz, 60Hz or last synced 50/60Hz (adaptive), 94-106Hz5), 74-76Hz |
| Power maximum (continuous / overload (<15s)) | 1200 W (1500 VA) / 2000 VA | 600 W (750 VA) / 1000 VA |
| Load sharing | ±5% of active power from 10 to 100% load |
| Current maximum (continuous / overload (<15s)) | 6.5 ARMS / 8.7 ARMS |
| Current (maximum) Quick trip (20ms) | 32 A (6 x nominal) |
| THD | < 1.5 % at resistive load |
| Protection | Fuse in L, Hot pluggable, Varistor |
| OUTPUT DATA |
| Voltage (default) / (adjustable range) | 53.5 VDC / 43 - 58 VDC |
| Power (maximum @nominal input) | 1200 W 1) | 150 W | 0 W 2) | 600 W 1) | 75 W | 0 W 2) |
| Current (maximum @VOUT ≤ 48 VDC) | 25 A 1) | 3.13 A | - 2) | 12.5 A 1) | 1.56 A | - 2) |
| Current sharing (10 - 100% load) | ±5% of maximum current from 10 to 100% load |
| Static voltage regulation | ±0.5% for 10 - 100% load |
| Dynamic voltage regulation | ±5.0% for 10-90% or 90-10% load variation, regulation time <
50ms |
| Rippel | < 200 mVPP , 30 MHz bandwidth |
| Protection | Short circuit proof, Over voltage shutdown, Reversed polarity,
Reversed polarity and Fuse |
| OTHER SPECIFICATIONS |
| AC Mains Input Voltage (range / LV disconnect) | 185 - 275 VAC / 170 VAC | 95 - 140 VAC / 85 VAC |
| AC Current (maximum) | 11.5 ARMS | 9.1 ARMS | 8.2 ARMS | 11.3 ARMS | 10.1 ARMS | 9.2 ARMS |
| Frequency (default: sync range) | 47-53 & 57-63 Hz | 47-53 & 57-63 Hz |
| Frequency (set-able: sync range) | 47-53 Hz, 57-63 Hz or both (adaptive) |
| Power Factor / THD | > 0.985 at 50% load or more / < 3.5% |
| AC Input Protection | Fuse in L and N, Hot pluggable, Varistor |
| DC Voltage nominal / extended range4) | 45 - 58 VDC / 40 - 45 VDC |
| DC Current (maximum) | 32 A / 45A during overload (15s) | 16 A / 22.5A during overload (15s) |
| OTHER SPECIFICATION |
| Efficiency | >96% (mains mode), >94% (inverter mode) | >92% (mains mode), >91% (inverter mode) |
| Isolation | 3.6 kVDC - ACPorts to PE, 3 kVAC - ACPorts to DCPort/CAN, 710 VDC -
DCPort to PE, 60 VDC - DCPort to CAN |
Alarms: Red LED
Alarm relay [NO max 75 VDC / 100 mA]
(AC output OR DC output alarms) | Low and high mains input voltage shutdown, High and low temperature
shutdown, Rectiverter Failure,
Overvoltage shutdown on output, Fan failure, Low output voltage
alarm, CAN bus failure, Sync bus
lost and Sync fail |
| Warnings: Yellow LED | Rectiverter in power de-rate mode or in power or current limit mode
on DC or AC port, Remote output
current limit activated, Loss of CAN communication with controller |
| Normal operation: Green LED | AC output and/or DC output on and ok |
| MTBF (Telcordia SR-332 Issue I method III (a)) | 260 000 hours (@ Tambient : 25 °C) |
| Operating temperature | -40 to +75°C (-40 to +167°F), humidity 5 - 95% RH non-condensing |
| Temperature de-rating above 55°C (131°F) | 1200W to 480W @ 75°C (167°F) for each, AC and DC, outputs (total
power 2000W to 800W) |
| Storage temperature | -40 to +85°C (-40 to +185°F), humidity 0 - 99% RH non-condensing |
| Dimensions[WxHxD] / Weight | 109 x 41.5 x 327mm (4.25 x 1.69 x 13”) / 1.95 kg (4.3 lbs) |
| DESIGN STANDARDS |
| Electrical safety | EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013, IEC/EN
62040-1:2008+A1:2013
UL 60950-1:2014, UL1778:2014, C22.2 No. 107.3-14 |
| EMC | EN 61000-6-1:2019, -6-2:2019, - 6-3:2007 + A1:2011, - 6-4:2019, IEC
61000-6-5:2015
EN 62040-2:2006, EN50121-4:2016+A1:2019, -5:2017+A1:2019
ETSI EN 300 386 V.2.1.1, FCC CFR 47 Part 15 |
| Environment | EU 2015/863 (RoHS) & 2012/19/EU (WEEE) / ETSI EN 300 019: 2-1
(Class 1.2) & 2-2 (Class 2.3)
Normal operating conditions as per IEC 62040-5-3:2016 clause 4.2.
Other operating conditions as per
IEC 62040-5-3:2016 clause 4.3, must be advised |
| | |
